Loa TOA gắn trần PC-2668
Rated Input | 6 W (for 100 V Line), 3 W (for 70 V Line) |
---|---|
Rated Impedance | 100 V Line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), (6.7 kΩ (1.5 W), 13 kΩ (0.8 W): Internal wiring must be changed) 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), (6.7 kΩ (0.8 W), 13 kΩ (0.4 W): Internal wiring must be changed) |
Sound Pressure Level | 90 dB (1 W, 1 m, 330 Hz – 3.3 kHz Pink noise) |
Frequency Response | 100 Hz – 16 kHz |
Speaker Component | 12 cm dynamic cone-type speaker |
Speaker Mounting Method | Spring catch Applicable Cable 600 V Vinyl-insulated cable (IV wire or HIV wire) Solid copper wire: φ0.8 – φ1.2 mm 7-core twisted copper wire: 0.75 – 1.25 m㎡ |
Connection | Push-in connector (Bridging terminal-2 branch type) |
Finish | Baffle: ABS resin, off-white (RAL 9010 or equivalent color) |
Dimensions | φ260 × 92 (D) (Exposed section) mm |
Weight | 820 g (Bracket included) |
